| Description | For Sale 1980 Vespa P200e
Price: $4500 FIRM
Color: Black
Runs: Great - Like a new scooter
Miles: 5 – since the completion of the restoration
Title: Clean with current registration
All parts are new Italian parts unless specified Piaggio OEM / Piaggio. This is a frame off restoration which took us approximately 6 months to build. Every part on this scooter has been replaced with new Italian parts with the exception of anything listed as Piaggio OEM.
Piaggio OEM – Original Equipment Manufacturer
Piaggio – New from Piaggio
Piaggio Stickers have been reproduced including the legshield
Rear Chrome BBQ Rack by Prima
Front Mudguard Bumper Chrome – F.A. Italia
Most of the hardware used for the restoration is stainless steel sourced from the US*
For more information or pictures of the build please email me at matt@ovvooptics.com or call 503.954.4043
Crankcase – Cylinder
1. Cooling Hood 120535
2. Crankcase Fitting Nut S.20107 Qty 12
3. Sprint Washer S.16407 Qty 12
4. Plain Washer fitting crank-case halves S.3057 Qty 11
5. Crankcase halves fitting studs S.11288 Qty 6 Piaggio
OEM
6. Spring Washer S.16408 Qty 4
7. Cylinder Sec. Stud S.553 Qty 4
8. Cylinder 414708 Piaggio
9. Packing 130977
10. Piston Ring Normal 136340 Qty 2 Piaggio
11. Oil Seal (Flywheel Side) 158962
12. Bearing (Flywheel Side) 133068
13. Crankcase Assembly 166234 Piaggio OEM Vapor
Blasted
14. Oil Seal (Clutch Side) 112156
15. Nut Sec. Cylinder Head and cylinder to crankcase
S.20108 Qty 4
16. Plain Washer sec. cylinder head and cylinder to
crankcase S.3058 Qty 4
17. Carburetor Sec stud S.521 Qty 2 Piaggio OEM
18. Packing 133184
19. Crankcase sec. bolt short S.12485 Qty 7
20. Rear Brake Adjuster Screw 23823
21. Nut for screw S20207
22. Nut S.20105
23. Clutch Adjusting Screw 156400
24. Crankcase halves securing bolt long S.14565
25. Engine for vehicles with auto mixer 164252 Piaggio OEM
26. Spacer Nut S.15239
27. Ring for wrist pin S.6616 Qty 2 Piaggio
28. Wrist Pin 119813 Piaggio
29. Piston Assembly Complete – normal 133918 Piaggio
30. Cylinder – piston - wrist pin assy. 156303 Piaggio
31. Set of Gaskets for overhauling engine with mixer device
154546 Piaggio
32. Sparking plug washer 318 (included with the spark plug)
33. Spark Plug NGK B8ES 137917
34. Cylinder Head 167108 Piaggio OEM vapor blasted
35. Bolt sec. cooling hood S.15593
36. Circlip S.6662
37. Spring Washer S.6968
38. Bearing (clutch side) 97804
39. Spring Plate S.8080
40. Plain Washer 97733
41. Self Tapping Screw S.14705
Crankshaft – Clutch – Automatic Mixer
1. Crankshaft, assembly 133153 MAZZUCCHELLI
2. Nut for securing flywheel magneto S.21112
3. Lock Washer S.12555
4. Flywheel Magneto Key 267
5. Damper Tube 94727
6. Damper Buffer 40316
7. Mixer Device Control Gear 113744 Piaggio OEM
8. Cage 151805
9. Key 97
10. Ring Nut Sec Washer 22313
11. Ring Nut 20375
12. Circlip S.6408 Piaggio
13. Plain Washer S.3056 Qty 3
14. Spring Washer S.16406 Qty 3
15. Bolt S.30050 Qty 3
16. Packing 17781
17. Breather 19301 Piaggio
18. Pressure Plate 25026
19. Circlip 14457
20. Actuating Pad 2/89858
21. Inner Lever 83806
22. Clutch Cover 113995 Piaggio OEM Vapor Blasted
23. Packing S.6708 Piaggio
24. Spring 46740
25. Outer Lever 97984 F.A. Italia
26. Clutch case 121201
27. Cup 21868 Qty 7
28. Spring 22821 Qty 7
29. Clutch Backplate 159853
30. Bush 2/59365
31. Rivet Qty 8 S.5790
32. Stop Washer 59109
33. Plate for engine gear 150082
34. Engine Gear 130823
35. Drive plate 59388
36. Driven Plate 93745
37. Drive Plate 50721
38. Circlip 38477
39. Clutch Assembly 131223 (see above)
40. N/A
41. N/A
42. Buffer (engine side) 174724
43. Washer 174539
44. Buffer (wheel side) 174723
45. N/A
46. Con rod – crank pin, assy. 132053 (inc above)
47. Shoulder Washer 58652 Qty 2
48. Bearing Securing Plate 58846 Qty 2
49. Stop Plate 58845 Qty 2
50. Nut S.20107 Qty 2
51. Circlip S.6964 Qty 3
52. Screw S.8339 Qty 3
53. Stud S.561 Qty 2 Piaggio OEM
54. Dosing Device Body 134913 Piaggio OEM – Vapor
Blasted
55. Mixer Gear 133226 Piaggio OEM
56. Washer 133223 Qty 2 Piaggio
57. Dosing Device packing 134914 Piaggio
58. Pumping Elements 133201 Piaggio OEM
59. Washer for spring 400282
60. Pinion 134865 Piaggio OEM
61. Packing S.6708 Piaggio
62. Spring of Piston 165260 Piaggio
63. Oil Pipe 134916 Piaggio OEM Vapor Blasted / zinc plated
Gear Group – Rear Wheel Hub
1. Washer 87714
2. 2. Circlip S.6647
3. Brake Jaw Newfren Slotted 72339 Qty 2
4. Circlip 61 Qty 2 Piaggio
5. Shaft for brake lever 97181
6. Packing S.6714 Qty 2
7. Split Pin for pin S.12761
8. Lever 131943
9. Split Pin S.3208
10. Spring Washer S.12539
11. Plate Securing Screw 121668 Qty 3
12. Dust Cover Chrome 78482
13. Cable Securing Nut S.21209
14. Back Plate 42047
15. Plate for shoes 24410 Qty 2
16. Pin for Plate 90306
17. Bolt sec. brake cable S.15510
18. Shoe return spring 78522
19. Bearing NGK 90025
20. Plate 94779
21. Oil Seal 130536
22. Split Pin S.12787
23. Drum Securing Nut S.2314
24. Wheel Securing Nut S.20108 Qty 5
25. Spring Washer S.16408 Qty 5
26. Drum Cover 92517 – Polished
27. Wheel Sec Stud Piaggio OEM
28. Brake Drum Piaggio OEM Vapor Blasted and clear coat
29. Selector spider 130939
30. Driveshaft 112858 – F.A. Italia
31. 4th Gear 152807
32. 3rd Gear 152806
33. 2nd Gear 152805
34. 1st Geat 152804
35. Packing for Plate 139433 Piaggio
36. Lever for return spring 78521
37. Packing for plate 78163 Piaggio
38. Gear Control Rod 130940
39. Washer 130941
40. Circlip S.6447
41. Shoulder Washer normal 18558
42. Washer sec. Cable S.13762
43. Screw for brake lining inspection hole 138241
Spring Gear – Kickstarter
1. D.C Roller Bearing 106956
2. Plain Washer S.16612
3. Stop Washer S.16305
4. Pin Securing Nut S.15231
5. Cap 46631
6. Lever Securing Bolt S.15861
7. Spring Washer S.16408
8. Plain Washer S.3038
9. Nut S.20008
10. Starter Lever Assembly 174312 – Polished
11. Protection Sleeve 49642
12. Packing S.6721 Piaggio
13. Starter Sector 148570
14. Lever Return Spring 47218
15. Spring for Starter Gear 139100
16. Spring Inner 77372
17. Oil Conveyor Rib 146129
18. Inner Ring 77371
19. Buffer 46742 Qty 2
20. Starter Gear 113526
21. Rivet S.5765 Qty 6
22. Outer Ring 77370
23. Outer Spring 78853 Qty 6
24. Gear Cluster 137334
25. Outer Gear Rim 112720
26. Spring Gear Assembly 131587 (Itemized above)
27. Pin 111715
28. Ball Bearing 112793
29. Roller 2457 Qty 21
30. Circlip S.6642
Flywheel Magneto – Electronic Ignition
1. Backplate assembly for electronic ignition 163910
Piaggio OEM
2. Plain Washer S.3055 Qty 9
3. Spring Washer S.6965 Qty 3
4. Backplate securing screw S.10047 Qty 3
5. Rotor with Fan 167102 Piaggio OEM Vapor Blasted –
Re-magnetized by Scooterwest
6. Flywheel magneto assembly 167103 Piaggio OEM –
tested, re-wired by Scooterwest
7. Plug 133652
8. Backplate with electronic ignition Piaggio OEM
9. Spring Washer S.16406
10. Cover sec. screw S.15545 Qty 2
11. Fan Cover Chrome 147568
12. Screw 2856 Qty 2
13. Washer 78307
14. Contact Plug 71482 – re-wired by Scooterwest
15. Terminal Plug 103130 Qty 5
16. Flywheel cover 166366
17. Coil No. 4 164118
18. Coil No. 1 163911
19. Coil No. 2 163912
20. Pick up with screw 181370
21. Coil No. 3
Carburetor – Air Cleaner
1. Cover securing Screw S.14569 Qty 2
2. Plug 87975
3. Air cleaner cover with cap 120762 Piaggio OEM Powder
Coated Black
4. Packing 58364
5. Packing 58853
6. Screw for securing air cleaner S.14436
7. Spring Washer S.16405
8. Screw for securing air cleaner box S.14743
9. Air Cleaner box assembly 285352 Piaggio (2 hole)
10. Main Jet 98051
11. Mixer 167060
12. Air Gauge of Mixer 150167
13. Slow Running Jet 120522
14. Group air filter mixer – OEM Piaggio Vapor Blasted
15. Dowel 133238
16. Starter Device sec. screw 2604
17. Cup cover sec. screw 92395
18. Spring Washer 92410
19. Cup cover 132369
20. Cap sec. screw 82934
21. Packing 82920
22. Cap 82933
23. Packing for air filter 82932
24. Mixture filter 82931
25. Cup cover sec. screw 97645
26. Packing 85296
27. Pipe securing screw 85294
28. Float Pin 85291
29. Packing 113312
30. Pipe 85295
31. Packing 150131
32. Starter Device 152133
33. Cover 131845
34. Cover securing screw 85418 Qty 2
35. Link 113010
36. Packing 85286
37. Throttle Valve 167059
38. Throttle slide return spring 93994
39. Packing 85467
40. Starter Jet 92712
41. Needle 150045
42. Screw 146086
43. Slow Running Adjuster Screw 137362
44. Adjuster Screw Spring 85285
45. Float 85293
46. Bellows 181476
47. Adjuster 2612
48. Lock – Nut 2613
49. Adjuster Screw Spring 26018
50. Adjuster Screw 85299
51. Carburetor Assembly 24/24E 285328 (Itemized Above)
52. Grommet 113060
53. Packing 133256 Piaggio
54. Air Cleaner Case 134912 Piaggio OEM – Vapor Blasted
55. Plug 113076
56. Screw S.15545
57. Packing 131115 Piaggio
58. Plain Washer S.13762 Qty 2
59. Spring Washer S.16409 Qty 2
60. Bolt 49542 Qty 2
61. Ball 14246
62. Spring 113291
63. Bush for Ball 133578
64. Grommet 113059
65. Lock – plate 146087
Gear Selector – L.T. Socket – H.T. Coil – Electronic Ignition
1. N/A
2. N/A
3. Cover sec. Screw S.15881
4. L.T. socket assembly 149082
5. Cap 142656
6. Screw sec. plate to engine S.15856 Qty 2
7. L.T. insulating cap 161125
8. Sparking plug Shielding cap (NGK) 29465
9. Selector bracket cover Chrome 138865
10. Slide Block Pin 46612
11. Slide Bloc 2/46613
12. Taper Pin S.13010
13. Selector Assembly 167300 (itemized)
14. Plain Washer S.6018 Qty 4
15. Plate Sec pin 59407
16. Plate 202503
17. Return Spring 59410
18. Adjuster Screw 90527 Qty 2
19. Gear control bracket assy. 167315 – Piaggio OEM –
Vapor Blasted
20. Nut S.20105 Qty 4
21. Gear Control Bracket 167305
22. Nut S.20107 Qty 2
23. Spring Washer S.16407 Qty 2
24. Plain Washer S.3057 Qty 2
25. Packing 47162
26. Cap 138345 Qty 2
27. Packing 397 Qty 2
28. Stud S.11288 Qty 2 Piaggio OEM
29. N/A
30. N/A
31. N/A
32. N/A
33. N/A
34. Buffer 141590 Qty 2
35. N/A
36. Plate 164844
37. Plain Washer Qty 2
38. Spring Washer S.16406 Qty 2
39. Screw S.15558 Qty 2
40. Bush 141589 Qty 2
41. Spring Washer S.16405 Qty 2
42. Nut S.20005 Qty 2
43. H.T. Cable 80341
44. N/A
45. N/A
46. Electronic Ignition Device 159576 Piaggio
47. Insulating Cap 185236
48. Insulating Cap for sparking plug screened cap 71671
49. Cam 167273
50. Pivot 167302
51. Strap 185365 Piaggio OEM – N/A
Saddle – Fuel Tank
1. Bolt securing fuel tank S.31119 Qty 5
2. Plain Washer securing fuel tank S.3058 Qty 5
3. Spring Washer securing fuel tank S.16408 Qty 5
4. Strap 175330
5. Rivet for Lever S.10860
6. Packing 2319
7. Filler Cap 16724 – Piaggio OEM – powder coated black
8. Fuel Tank assy 160627 – Piaggio OEM – powder coated
black
9. Tie Bolt 4435
10. Cap Securing Nut Chrome 92217
11. Split pin S.3212
12. Filter assy 138934
13. Fuel tank Gasket 159804
14. Packing of fuel cock S.6068
15. Fuel cock sec. nut
16. Fuel cock assy. 180056 – Piaggio
17. Ring Nut upper 156490
18. Jointing piece for oil filter 156038 – Piaggio
19. Plain Washer 156082
20. Oil Tank 137353 – F.A. Italia
21. Upper packing securing tank 156491
22. Packing 156039
23. Euro Fuel Tap
24. Spring Clip 15467
25. Case with cock 147045 – N/A
26. Packing for fuel cock 13836
27. Gear with lever 147047 – N/A
28. Spring sec. tube 97248 Qty 1
29. Distributor Cover 147274
30. Grommet 84262
31. Fuel Line 104293 – 24” Italian
32. Strap (Euro style clamp) 104296 Qty 2
33. Pressure Spring 158893
34. Spring sec screw S.10011 Qty 2
35. Fuel Cock Lever 217871
36. Hook for Bag (closed type) 57468
37. Hook securing nut S.20105 Qty 2
38. Fastening Plate 57371
39. Hook sec Bolt S.14415 Qty 2
40. Spring Washer S.16405 Qty 2
41. Cup for oil Indicator 102584
42. Inner element for oil indicator 103155
43. Packing 102587
44. Packing on the frame for oil indicator 102586
45. Plug for oil indicator 102585
46. Packing on the frame for oil pipe 15478 – N/A
47. Pipe between oil tank and mixer device 104294 – Italian
48. Spring Ring S.6407 – N/A
49. Nut S.21210
50. Lock sec. screw S.31027 Qty 3
51. Spring Washer S.16404 Qty 3
52. Name Plate Support 163276 – Piaggio
53. Nut for securing pillion seat and spring S.20106 Qty 4
54. Plain Washer S.3055 Qty 2
55. Screw S.8455 Qty 2
56. Piaggio Name Plate 181236
57. Plate for helmet 162035 – Piaggio OEM – Powder coated
Chrome (silver)
58. Lock for body with key 163259
59. Stop Plate 161509
60. Return Spring 161512
61. Plain Washer 89242 Qty 2
62. Grip Sec. Screw S.15862 Qty 2
63. Saddle Cover 149914
64. Dual Saddle Assembly 149913 (Itemized)
65. Grip 149973
66. Spring Sec. screw S.14417 Qty 4
67. Plain Washer S.13880 Qty 4
68. Lock for saddle assembly 161548 (Itemized)
69. R.H. central spring 90731 / L.H. central spring 90732
70. Bottom of the lock housing 161510
71. Clip 94720 Qty 18
72. Buffer 163778 Qty 2
73. Saddle Lock Pin 161513
74. Spring Washer S.16408
75. Plain Washer S.3058 Qty 2
76. Return Spring for lock body 164601
77. Saddle central bracket 98834
78. Tyre Pump – Piaggio OEM
79. N/A
80. N/A
81. Spring Plate S.8080 Qty 2
82. Self-Tapping Screw S.8455 Qty 2
83. N/A
Frame
1. Vespa front name plate 152541
2. Piaggio Emblem 149876
3. Steering column cover Chrome 149874c
4. Windshield Beading Cuppini 149943
5. Frame 163913 Piaggio OEM Powder coated black
6. Self-Tapping screw S.15737 Qty 2
7. Plain Washer S.3055 Qty 2
8. Plate 157922 Qty 2
9. Self-tapping Screw S.8372 Qty 2
10. Plug 157716 Qty 2
11. Name- Plate 181325
12. Name Plate 180587
13. Screw S.15891
14. Rear protection of frame 162105
15. Plate 181475 Qty 2
16. Frame Sec cover 2/87019
17. Driving Mirror Left and Right Cupini 90845
18. Nut sec. License Plate S.20104 Qty 4
19. Screw securing License Plate Qty 4
Cowls – Glove Compartment
1. Buffer between flap and glove compartment 149908 Qty
4
2. Washer 56649
3. Packing between glove compartment and windshield
149979
4. Upper Bolt S.6777 Qty 2
5. Lock Washer S.12528 Qty 4
6. Nut S.20105 Qty 8
7. Stop Plate 73260
8. Spring 73111
9. Key for lock 120329
10. Lock for glove compartment (Itemized)
11. Flap 149996 – Piaggio OEM powder coated black
12. Glove compartment 181903 – Piaggio OEM powder
coated black
13. Rivet 97523 Qty 2
14. Lock Couple 154754
15. Spring for tool canvas 12218
16. Lower Screw S.6777 Qty 2
17. Nut S.12112 Qty 2
18. Plain Washer 97733 Qty 2
19. Spring 83115 Qty 2
20. Grommet Qty 2
21. Grip R.H. Chrome 83113
22. Grommet 156946
23. Grommet 70286
24. Nut for securing spare wheel and silencer S.20108 Qty 2
25. Spring Washer for securing spare wheel and silencer
S.16408 Qty 2
26. Packing strips for engine cowl 161995 Packing strips for
cowl L.H. 161994
27. Strip sec rivet S.18020 Qty 2
28. Rubber Spacer 56654 Qty 2
29. Bush for pin (turn signal lamps) 146782 Qty 2
30. Spring Plate S.8108 Qty 4
31. Rivet S.10764 Qty 4
32. Spring for engine cowl 73954 Qty 2
33. N/A
34. P 200 E Name Plate 181328
35. Tube for engine cowl 24041 Qty 2
36. Spring Washer S.6968
37. Bolt 159873
38. Engine Cowl 161411 – SIP powder coated black
39. Cowl L.H. 161412 – SIP powder coated black
40. L.H. tie rod chrome 54890
41. Spare wheel protection stainless steel 159875
42. Wheel assy chrome Michelin tire S1 3.50x10 84635
Front and Rear Dampers – Security Lock
1. Spring Washer S.16408 Qty 2
2. Spring Washer S.16409 Qty 3
3. Nut S.20008
4. Spring Bracket 60536
5. Rear damper sec. nut S.20209
6. Spacer 149871
7. Rear damper 174238 Carbone powder coated silver
8. Rear suspension spring 70646 Carbone powder coated
silver
9. Lower Bolt S.14689
10. Nut S.21214
11. Spring Washer S.16414
12. Bolt 81803
13. Lower screw sec. damper S.30074 Qty 2
14. Nut S.20108 Qty 4
15. Gasket 174092
16. Spring Washer S.12535
17. Nut S.21210
18. Spring Washer S.16408 Qty 4
19. Screw S.31119 Qty 2
20. Buffer 174083
21. Upper Buffer 174085 Qty 2
22. Plate 174806
23. Upper Washer 174088
24. Dust Cover 19264
25. Inner Track of lower bearing 55989
26. Ball Cage 77023
27. Outer Track 92667
28. Lower Track of upper bearing 56641
29. Ball Cage 77024
30. Upper Ring Nut 55986
31. Stop Washer 3751
32. Upper ring nut 11109
33. Security lock housing 152096
34. Cover 174628
35. Self-Tapping Rivet 174629 Qty 2
36. Key 120329 Qty 2
37. Outer Sleeve 174078
38. Upper plate 174084
39. Front Suspension Spring 174079 Carbone Powder
coated silver
40. Inner sleeve 174805
41. Lower Plate 174054
42. Protection tube 174082
43. Buffer 137389
44. Spring 152195
45. Adjuster screw 90527
46. Nut S.20105
47. Bolt 2036
48. Pin 90305
49. Brake Link 83608
50. Brake link 97108
51. Ring Nut S.12761
52. Nut S.20207
53. Brake Control Lever 174025
54. Protection Tube 70635
55. Bearing Ball track upper 153025
56. Bearing ball track, lower 153024
57. Front damper assembly 174446 Carbone
Profile Strips – Center Stand – Silencer
1. Terminal pad for profile 159828 Qty 12
2. L.H. inner strip 180031
3. R.H. inner strip 180030
4. L.H. middle strip 180029
5. R.H. middle strip 180028
6. L.H. outer strip 180027
7. R.H. outer strip 180026
8. Rubber profile strip 159829
9. Terminal pad rivet S.10868 Qty 2
10. Inner strip sec. rivet S.10869 Qty 8
11. Buffer 174773
12. Strip sec. inner rivet S.10805 Qty 20
13. Cup 174918 N/A
14. Self-tapping screw 181820 Qty 8
15. Rubber mat 180052
16. Spring 174880 Qty 2
17. Spring Washer S.16410
18. Silencer securing bolt S.14691
19. Silencer assy 161580 – Sito Plus Exhaust
20. Center Stand and Pads Chrome 174798
21. Stand pad 174919
22. Plate for strip 77252
23. Center Spring 174964
24. Stand securing bolt S.31089 Qty 4
25. Spring Washer S.16406 Qty 4
26. Nut S.20006 Qty 4
27. R.H. Bracket 174875 L.H. Bracket 174874
28. Mat Retainer Strip 180048 Qty 2
29. Washer securing stand S.3056 Qty 4
30. Ring Nut 130143 – Piaggio
31. Strap for sec silencer to the cylinder, assy 140528 – Sito
Plus
32. Bolt S.14691
33. Spring Washer S.16410
34. Terminal Pad rivet S.10881 Qty 2
Steering Column – Mudguard – Wheel Hub
1. Upper nut sec. Mudguard S.20106 Qty 3 – stainless steel
2. Upper Washer securing Mudguard S.13880 Qty 6
3. Lateral washer securing mudguard S.6018
4. Nut 126409
5. Stud 85914 Qty 5 – Piaggio OEM
6. Cap 181757 – Polished
7. Spring Washer S.16408 Qty 5
8. Brake drum sec. nut S.20108 Qty 5
9. Brake Drum 181812 – Piaggio OEM – vapor blasted –
clear coated
10. Plate for brake jaws 174023
11. Packing 174363 – Piaggio
12. Spring Plate 85508 Qty 2
13. Mudguard 174120 SIP Powder coat Black
14. Ring 174601
15. Packing ring 174887
16. Spacer 174035
17. Spacer 174040
18. Bolt S.30050 Qty 3
19. Plain Washer 97733 Qty 6
20. Circlip S.6418
21. Bearing S.7135
22. Spring Washer S.16406 Qty 3
23. Mudguard sec. nut S.20105 Qty 4
24. Steering Column 174118 Piaggio OEM Powder coat
chrome (silver)
25. Spring Washer S.6632
26. D.C. Roller Bearing 132094 Qty 2
27. D.C. Roller Bearing 174710
28. Packing ring S.17019
29. Cover 174359
30. Plate 24410 Qty 2
31. Circlip 61 Qty 2
32. Jaw Return Spring 78522
33. Brake Jaw 72339 – Newfren slotted
34. Bolt S.14467
35. Lock Washer S.12528
36. Drive Pinion Housing 174128
37. Speedometer drive pinion 174048
38. Grommet for speedometer Outer cable 174129
39. Plate sec. speedometer outer cable 174130
40. Spring Washer S.16405
41. Bolt S.31056
42. Crest Chrome 181904
43. Suspension arm front 174044 – Piaggio OEM – Powder
coat Chrome (silver)
44. D.C. roller bearing 174099 Qty 2 – Piaggio OEM
45. Pin 174098 – Piaggio OEM
46. Packing 174881 Qty 2
47. Packing Ring 138725 Qty 2
48. Screw for brake lining inspection hole 138241
49. Return spring for brake lever 181822
Handlebars
1. Handlebars assy. 163327 Piaggio OEM
2. Handlebar shell 139829 – Carbone Fiber print
3. Lower part of the handlebars 139775 – Piaggio OEM –
Powder coat black
4. Packing 138791
5. Speedometer Housing 185391 – Piaggio OEM – restored
by Speedo King
6. Washer 181762 Qty 3
7. Washer 139890 Qty 2
8. Box securing nut 139915
9. Pulley anchorage gear change cable 139796
10. Pulley anchorage throttle slide 139797
11. Spring Clip 137267 Qty 2
12. Cable end cap for brake and clutch 18669 Qty 2
13. Grip 141923 Qty 2 – Piaggio
14. Cable end cap for gear change 139913
15. Twist grip throttle sleeve 175370 – Piaggio OEM
16. Brake and clutch lever 138336 Qty 2 – Polished
17. Cable end cap for gear change and throttle slide 139912
Qty 2
18. Return spring for throttle twist grip 175369
19. Washer securing cover S.3055 Qty 2
20. Screw Sec Cover S.15835 Qty 4 – Piaggio
21. Lever securing screw 150235 Qty 2
22. Spring Washer 17492 Qty 2
23. Plain washer 97734 Qty 2
24. Lever sec. nut S.12136 Qty 2
25. Gear shift sleeve 139918 – Piaggio OEM Powder coated
Black
26. MPH speedo bulb socket 163190
27. Hardlebars sec. nut S.15542
28. Harndlebars sec. nut 70620
29. Plate 139914 – Piaggio OEM
30. Plain Washer 97733 Qty 2
31. Bulb for MPH speedo 71632 12v 2w
32. Cap for bulb socket of the MPH speedo 163895
33. Socket for neutral indicator light 185364 – Graybar /
SIEM
34. Bulb 71632 12v 2w
35. Cable tag S.15008
36. Contact Plug 71054
37. Insulating Tube 71037
38. Insulating Piece 146371
39. Grommet 75931
Transmissions – Cable Controls
1. Cable hose and cap 139626 Qty 2
2. Cable end cap 147511 Qty 10
3. Cable with terminal 107089 Qty 2
4. Gear transmission assembly 139402 Qty 2
5. MPH speedo transmission assy. 174161
6. MPH speedo cable with washer 174160
7. Speedometer transmission ring nut 401856
8. Bracket for rear brake pedal 138474 – Piaggio OEM –
Vapor Blasted
9. Washer securing rear brake pedal S.13880 Qty 2
10. Rear brake Pedal 182049 – Piaggio OEM – Vapor
Blasted
11. Rubber Pad 182051
12. Bolt securing pedal S.31088
13. Bolt securing pedal S.31091 Qty 2
14. Spring washer securing pedal S.16406 Qty 2
15. Nut securing pedal S.20106 Qty 2
16. Cable securing nut S.21209 – N/A
17. Spring Washer S.12539 – N/A
18. Bolt S.15510 – N/A
19. Protective Sleeve – Piaggio
20. Plate for securing transmission 82385
21. Cable screw nipple assy. 153198 Qty 3
22. Washer 401855
23. Rear Brake Cable, assy. 174701
24. Cable securing clip 83333
25. Rear brake cable sheath 174012
26. Securing box for nut 70146
27. Rear brake cable 94094
28. Cable end cap 23825
29. Square nut 70147
30. Retainer cap 90529 (Replaced with shrink tubing)
31. Plate 175063
32. Washer 162110
33. Recovery spring for brake lever 70994
34. Pin 70122
35. Pin S.8818
36. Plate securing cable 42047 – N/A
37. Pin for plate 71165
38. Split pin for pin S.12761
39. Plain washer S.13762 – N/A
40. Starter control sheath 50188
41. Ring 77055
42. Starter control transmission 92370
43. Starter control cable 92371
44. Spring 50207
45. Rod with knob chrome 155541
46. Clutch control cable 19061
47. Nipple 2777 Qty 2
48. Clutch control sheath 175324
49. Throttle control sheath 174351
50. Nipple carburetor side 143849
51. Throttle control Cable 139630
52. Nipple 90511 Qty 2
53. Front Brake Sheath 175222
54. Front brake cable 174162
55. Throttle control transmission 174830
56. Front brake transmission 175225
57. Clutch control transmission 175325
58. Grommet 48171
59. Inner sleeve of front brake 175221
60. Stop switch assy. 175120
61. Cable Terminal 2174 Qty 2
Wheel – Tool Kit N/A
1. Nut S.20108 Qty 10
2. Spring Washer S.16408 Qty 10
3. Wheel Rim Chrome 3.50x10 84629 Qty 2
4. Inner Tube Michelin 3.50x10 Qty 2
5. Wheel rim, assy 84631 Qty 2
6. Wheel assy 84635 Qty 2
7. Tire Michelin S1 2/158703 Qty 2
8. Wheel flange chrome 84630 Qty 2
Tool Kit can be purchased separately on Ebay
Headlamp – Tail Lamp – Switch – Horn
1. Screw S.8531
2. Plain Washer S.13769
3. Stop switch, rear 73611
4. Switch securing bolt S.31033
5. Packing 70144
6. Contact Plate 73612
7. Contact Plate 73547
8. Push button 70140
9. Spring 55325
10. Shoulder washer 55322
11. Spring 70141
12. Contact Plug 73546
13. Spring 141077
14. Bulb for tell tale lamp 163656 12v 2 w
15. Nut S.20104
16. Ring 175682 Piaggio OEM
17. Spacer 175791 Qty 3 – Piaggio OEM
18. Plain Washer S.3055 Qty 2
19. Headlamp Insert 174873 12v 35w Sealed Halogen
20. Clamp Plate 163603
21. Headlamp Assembly 139600
22. Horn securing screw S.15727 Qty 7
23. Horn 163750 – Piaggio OEM
24. Key Operated Switch 160743 – 8 Pole
25. Key for switch 164501
26. Spring washer securing stop – switch S.16404
27. Packing 163283 N/A
28. Rear Lamp Assembly Chrome 58269R Piaggio / SIEM
29. Plain Washer S.3056 Qty 2
30. Rear Lamp sec. Bolt S.31088 Qty 5
31. Plain Washer S.3054
32. Bulb for rear lamp 129953 Ba15s
33. Tell Tale Lamp 163331 – Piaggio OEM
34. Grommet 175790 Qty 3 Piaggio OEM
35. Support 185486 Piaggio OEM – Powder coat Chrome
(silver)
36. Switch with horn push button 182143 – Graybar
37. Cover 163151 – Graybar
38. Cover Sec. Screw S.15640
39. Headlamp Rim 139592 – Piaggio OEM – Powder coated
black
40. Spring 175794
41. Inner Ring 175672 – Piaggio OEM
42. Spring Washer S.12532 Qty 2
43. Spring Washer S.12533 Qty 2
44. Tail Lamp Support 123526 – N/A
45. Washer S.16406 Qty 3
46. Nit S.20106 Qty 3 – N/A
47. Reflector 152897 Qty 2 – N/A
48. Packing 158064 Qty 2 – N/A
49. Plate 181351 Qty 4 – N/A
50. Switch 164873 – Graybar
51. Tag 156206 Qty 3
52. Pin for cables 122429 Qty 2
53. Pin for cables 101906
54. Contact Plate 103130 Qty 2
55. Electrical Cable 24583
56. Headlamp Sec. Screw S.838 Qty 2
57. Buffer 175681 Qty 2
58. Headlamp setting screw S.30235 Qty 2
59. Spring 175679
60. Screw S.702 Qty 2
Electrical Connections
1. Wire 24577
2. Insulating Sheath 79343 Qty 2
3. Clip 145298
4. Insulating Tube 87396
5. Insulating Tube 87404
6. Insulating Tube 87394
7. Wire 87805
8. Insulating Tube 87405
9. Contact Plug 101906 Qty 15
10. Grommet Qty 2
11. Cable Harness (turn signal lamps) 164872
12. Electrical cable, assy. Turn signal lamps 149183
13. Current Tap, Turn signal lamps 122429 Qty 4
14. Insulating piece, turn signal lamps 146787 Qty 2
15. Tag, turn signal lamps 146788 Qty 2
16. Clamp Plate 163825 Qty 2 – N/A
17. Tag, turn signal lamps S.15001 Qty 2
18. Tag, turn signal lamps S.15002 Qty 2
19. Grommet, turn signal lamps 142300 Qty 2
20. Grommet, turn signal lamps 119975 Qty 2
21. Insulating sheath 71037 Qty 6
22. Current Tap 71160 Qty 3
23. Cable Terminal S.15001 Qty 3
24. Wire 87402
25. Sheath 87393
26. Insulating Sheath 87399
27. Wire 85721
28. Wire 24583
29. Contact Plug 71482 Qty 13
30. Insulating Tube 141992
31. Insulating Cap 143393 Qty 3 – N/A
Turn Signal Lamps – Battery
1. Tell tale lamp assy. 163332 Piaggio OEM
2. Bulb for tell-tale lamp 163656
3. Turn signal lamp switch assy. 163140 – Graybar
4. Cover 163142
5. Switch sec. screw S.15640
6. Regulator 160767 – 5 Pin
7. Screw S.8375 Qty 2
8. Plain Washer S.3056 Qty 2
9. Spring Washer S.16406 Qty 2
10. Spring Support securing thermal cutout 164344 Piaggio
OEM
11. Turn Signal Lamp L.H. Chrome 162817 / Turn Signal
Lamp R.H. Chrome 163256
12. Turn signal lamp securing screw S.15751 Qty 4
13. Turn signal lamp securing nut S.20004 Qty 8
14. Lock Washer S.12531 Qty 10
15. Turn signal lamp rear R.H. Chrome 160998 / Turn signal
lamp rear L.H. Chrome 160999
16. Securing bolt S.31027 Qty 4
17. Bulb for turn signal lamps 160654 Qty 4 12v 21w*
18. Battery Holder 162518 – Piaggio OEM – Powder coated
black
19. Holder sec. screw S.15588 Qty 4
20. Spring Washer S.12533 Qty 4
21. Strap 90854
22. Buffer for Battery 163748 Qty 4 Piaggio
23. Insulating cap 167304
24. Fuse Holder 142519 – Piaggio OEM
25. Thermal Cut out 164356 – 12v 3 pin
26. Battery 164127 SIP Sealed 12v 5.5 Ah
27. Fuse 2/24967 – 8 amp German style
28. Strap 143253
29. Screw S.31087
30. Plain Washer S.3056
31. Buffer for battery 164887 Qty 2 Piaggio
32. Spring Washer S.16406
33. Nut S.20106
34. Switch for neutral indicator light 126938
35. Nut S.15259 |
